Molybdenum Spraying Wire

Molybdenum Spraying Wire




Manufacturing process of molybdenum spraying wire:

Molybdenum spraying wire

is made from molybdenum bar by heating, rolling and drawing. Pioneer also produce

molybdenum disulphide

by using hydrogen furnace.

Molybdenum spraying wire applications:
Molybdenum spraying wire has become an indispensable material for metal spraying technology. Molybdenum spraying wire is sprayed thermically on surfaces of mechanically strongly stressed automobile parts, such as piston rings, synchronizer rings, shift elements to increase their abrasion resistance. Further more, molybdenum spraying wire is also applied as intermediate layer in the case of repairs of machine parts, such as bearing shells and shafts.

Molybdenum spraying wire is mainly used in the fine spray of automobile wear parts surface and mechanical wear surface to enhance the wear-resisting property.

Molybdenum disulfide is insoluble in water, but only soluble in aqua regia and boiling concentrated sulfuric acid. Molybdenum disulfide is  important solid lubricant and is especially suitable to be applied under high temperature under high pressure. In addition, molybdenum disulfide also has anti-magnetism and can be used as linear photoelectric conductor and semiconductor with conductive property. Molybdenum disulfide is featured by rectification and energy transfer effects.

Molybdenum disulfide is also known as "the king of advanced solid lubricant". The color of molybdenum disulfide appears black with silver gray and molybdenum disulfide has metallic luster. Molybdenum disulfide has soapy feeling feels and such advantages as good dispersity and no adhesion. Molybdenum disulfide can be added into a variety of greases to form non-sticky colloidal state to improve the lubricating property and extreme pressure property of grease. Molybdenum disulfide is also suitable to be used in mechanical working state with high temperature, high pressure, high speed and high load to prolong the service life of machines.

Properties of molybdenum spraying wire:
Molybdenum spraying wire has high abrasion and wear resistance.

Specifications of molybdenum spraying wire:
Diameter 3.175mm, 2.3mm-1.41mm
Tolerance  3. 175mm + / -0. 025mm or + / -0. 05mm
 3mm-1. 45mm + / -0. 02mm +/ -0. 05mm
Tensile Strength  >700-900N / mm2
Elongation >20-5%
